Window Exhaust Fan

Window or Wall Mounted Exhaust fan

WINTEK, is a manufacturer of Exhaust Fan with over 20 years of manufacturing experience, specializing in providing the OEM, ODM, OBM service. We are a customer-oriented manufacturer that could realize your new marketing requirement. High cost-effectiveness and Strict quality control stengthen your competitiveness in the market. If you are looking for a reliable Exhaust Fan manufacturer, then please contact us. Below are our most popular products.

Our Products:

You could gain benefits by choosing us.

Wintek is a reliable manufacturer of exhaust fan in China. We factory have been supplying to numerous huge brands all over the world, specializing in providing OEM,ODM,IDM service.

Our bathroom exhaust fan has the following market-leading advantages:

1. Competitive price. Devoting in bathroom exhaust fan for over 20years, we formed a complete cost-control system to ensure our price is the best.

2. High quality. We offer one-year warranty and our products have 3 year life in normal usage. We use 100% copper wire and permanent lubricated motor.

3. Quick deliver. We have strong production capacity and is able to do customization as your demand.



Benefits of Window Fans
There are a number of benefits that come with having one or two, or several window fans in your home. First and foremost, they can help reduce energy costs by making air conditioning units more efficient. They don't require any tools and can be installed quickly and best of all, Holmes Window Fans have been specifically designed to fit almost any kind of window.

The primary benefit of a window fan is that it can be used to pull in cool, fresh air from the outside or, it can be used to exhaust stale indoor air. With an electronically reversible fan such as the Holmes® Electronically Reversible Twin Window Fan, you get the added bonus of one fan blade pulling in the fresh air and the second one blowing out the stale, indoor air. Additional features may also include thermostats, remote controls and temperature displays. These are great for providing optimal comfort as you have the ability to customize settings according to your schedule and room temperature preferences.











What is Window Mount Exhaust Fans

A  window exhaust fan is generally a popular choice for bathroom installation and they are typically found in apartments and unit blocks. In this post we will look at suitable positioning, how the fan is installed and wiring options.

A window can be a good choice of location for an exhaust fan as they are generally located opposite the door. With any bathroom exhaust fan your aim is to create a good cross flow of ventilation, allowing for the greatest amount of air circulation possible. So ‘fresh’ air enters under the gap between the door and the floor and is exhausted out via the window fan across the room. See the below diagram for an ideal setup:

If your window is poorly positioned you may wish to consider other means of exhausting, such as a wall mount exhaust fan and window mount exhaust fan.







How to install a Window Mount Exhaust Fan

An exhaust fan should not be confused with an ordinary window fan. The window fan is used to circulate air from the outside into the room for a cooling effect. The window exhaust fan is used to drive the air out of the room.

Step 1 - Remove the Window Pane

Before you can install an exhaust fan into a window you will need to remove the window pane. This can be done easily if you are working with a double pane window. Simply remove it from the casing.

Step 2 - Replace Glass with Lexan

If you try to install the window exhaust fan into a pane of glass, you run the risk of cracking the glass and having to replace it anyway. Lexan is a strong material that can be used as a replacement for the glass that you can see through and clean very easily.

Step 3 - Outline Exhaust Fan onto Lexan

Using the casing of the exhaust fan as a guide, you can trace the outline onto the center of the Lexan piece. Make sure that the case is level before you start to draw on the Lexan material.

Step 4 - Cut Out Hole for Fan

There are two ways that you can cut the Lexan material for installing the fan. The first way is to drill a hole in the corners and cut with a jig saw. This can cause some splintering of the material. Another way is to score it with a glass cutter and tap out the piece when you can score it several times. This will leave a clean cut without any ragged edges.

Step 5 - Replace Window

Once the hole has been cut, and the Lexan has been installed, you can now replace the window back into the casing.

Step 6 - Install Fan

With the window back into the casing, you can install the exhaust fan. Remove the front cover of the fan so you can easily slide the motor into the casing.

Step 7 - Drill Holes for Screws

Set the case back onto the Lexan and mark for the holes that are for the mounting screws. Remove the case and drill the holes with a cordless drill. Be careful and drill straight into the Lexan and not to the side.

Step 8 - Mount Case

Set the case back onto the Lexan and screw in the bolts from the outside. Use the locking nuts to secure them into position.

Step 9 - Set Fan in Case

With the case mounted, set the fan inside and secure with the retaining screw. Place the cover over the fan and plug into the the closest outlet.
